• EXARK EX-6024 RFID METAL ASSET TAG

    EXARK EX-6024 RFID METAL ASSET TAG

    EXARK EX-6024 is a passive UHF RFID Label for Mount on Metal applications demanding long read range in small form factor with a high performance permanent adhesive.


    Click here to download the Datasheet

    Enquire Now

    • High performance permanent adhesive ensures strong adhesion
    • disposable layer between each RFID label ensures efficient Thermal transfer printing.
    • label with all round performance that can be deployed across a wide range of industries.
    • ideal for asset tracking of medical devices, IT (Information Technology) asset tracking, industrial asset tracking, tracking high value/luxury retail items, etc.
    ELECTRICAL:

    Standards
    EPC Global Class1 Gen2 ISO 18000-6C

    Frequency Ranges
    Global 860-960MHz

    IC type
    NXP UCODE 8

    Memory configuration
    EPC96 bits extensible to 128-bits

    Read range
    Up to 10ft/ 3 m

    Mode of Operation
    Passive

    MECHANICAL:

    Substrate
    PET

    Liner
    Glassine Liner

    Face material
    PET

    Tag dimensions
    60x 24×1.2 mm

    ENVIRONMENT:

    Operating Temperature
    -20°C~75°C

    Operating Humidity
    -20°C~85°C

    Storage Temperature
    -20°C~75°C

    APPLICATION INTERFACE:


    Used In Solutions
